Parallel twin screw barrel for Weber DS85 extruder machine

Price: 8800.0~9600.0 USD
Payment Terms: T/T,WU
Place of Origin: Zhejiang, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: XR-SJP85
Packing: Film wrapped in wooden case...
Brand Name: SHEEN SCREW
Screw barrel HS code: 8477900000
Screw barrel application: PVC Pipe extruder
Screw barrel thickness of nitrided layer: 0.5-0.8mm
Bimetalic material: tungsten carbige 40%
Bimetallic layer of screw: 2.5mm
Means of Transport: Ocean,Air
Delivery Date: 25 working days upon receip...
Screw barrel material: High quality alloy steel 38...
Screw barrel certificate: ISO9001:2008
Screw barrel nitrided hours: 120 hours
Screw barrel hardness of nitrided layer: HV900-1100
Bimetalic screw processing way: PTA

Parallel twin screw barrel for Weber DS85 extruer machine
Screw type:double Screw diameter:85mm L/D=17

About SHEEN SCREW

Zhoushan Sheen Machiney Company is leading supplier of SCREW and BARREL in china,including designing,manufacturing and sales for these products,we can make any specification of extruder screw barrel and injection molding screw barrel for Haitian,Demag,Engle,Nigrobossi,KMD,NPM,BOY,HUSKY, Nippon Steel, Toshiba, Nissei, Mitsubishi and etc. We also can supply all types of screw and barrel according to your different requirements.



What is our Screw and Barrel advantage:

First:Cretive in designs,our desinging team is very strong,since we have unique culture to motivate them,in order to meet requirement,we work closely to our customer and market!

Second:We have 15 years' experience of manufacturing varied screws, barrels and spares.We are keeping improving our production stytem day by day on the delievey,quality control,all the efforts have improved the customers satisfaction!

Third:We are located in China's screw Town-Jintang,Town in zhoushan city,near to Ningbo Port and Shanghai Port!

Finally,We assure the customer benefits,we supply best quality and competitive price,also best customer service!


Parallel twin screw barrel for Weber DS85 extruer machine Specification:

(Co-rotating and Counter-rotating)Parallel twin screw and barrel:

Φ35/2

Φ45/2

Φ50/2

Φ65/2

Φ80/2

Φ90/2

Φ105/2

Φ125/2

Φ130/2

Φ150/2

Φ180/2

Φ200/2

Features:Screw and Cylinder adopt blocking structure, can update and maintain comfortably!

Screw&Cylinder also can be made:

CINCINNATI, BATTENFELD, KRUSSMAFFEI, BAUSANO and AMUT model spares!

According to different material and plastic product to choose different compress rate and L/D!

Advantages

1. Parallel twin screw and barrel has the advantage of lower rotation speed, smaller shear   stress between the  small screw

2. Good plasticization, high productivity, small shear force, stable pressure , less wear and tear and low cost.

3. Parallel twin-screw and barrel is widely used in PVC products processing, especially for the production of PVC products with the output over 350Kg / h, because the parallel twin-screw and barrel costs less than conical twin-screw and barrel while it has more mature technology.

4. Parallel twin-screw and barrel is successfully applied in PVC plate, pipe, profile, pellet and mould, at the same time, it solved the technical problem of low foaming, high foaming, high filling, wear and corrosion.



Detailed Technical Information:

Base Material

1)38CrMoAlA(JIS SACM645) 2)Cr12MOV(JIS SKD-11)
3)4Cr5MoSiV1(JIS SKD-61)  4)42CrMo(AISI 4140)

Bimetallic Alloy Materials

1)Fe-based alloy  2)Ni-based alloy/Deloro alloy
3)Co-based alloy  4)NiCo-based alloy
5)Tungsten carbide/Wolfram carbide

Double-alloy level

Level A - containing Tungsten of 40%

Level B - containing tungsten of 25%

Level C - containing tungsten of 9.5%

Surface Treatment

Heat Treatment

High Frequency Treatment

Nitriding treatment(120 Hours)

Depth of Nitrided Layer: 0.5-0.8 mm

Hardness of Nitrided Layer: 900-1020Hv (HRC56°-65°)

Hard Chrome Plating treatment:

Thickness of Hard Chrome Plating Layer: 0.05-0.10mm

Hardness of Hard Chrome Plating Layer: ≥950HV

Nickel alloy plating.treatment:

Bimetallic Barrel/Cylinder: Centrifugal Casting (Inlay Alloy)

Bimetallic Screw: Plasma Alloy Coating Spraying

Depth of Bimetallic Layer: >2mm

Hardness of Bimetallic Layer: HRC55°-72°

Basic information

Roughness of the surface:Ra0.4um

Linearity of the screw: ≤0.015mm

Linear axis limit: ≤0.02mm

Hardness after Hardening & Tempering: HB240-280

Fragility of Nitration:≤Two class

Material Application

1)General Plastics

2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc

3)PA + GF(Glass Fiber)

4)Flame-resistant Reinforced Plastics

5)Modified Engineering Plastics

6)All kinds of Mixed Recycled Material(in Scrap or Granule),etc

General Terms

Means of transport: Ocean,Air,Express

Production time: About 25 days after we receive the deposit and lead time will different according to the order quantity!

Our products advantages

1)High productivity        2)Wonderful plasticizing

3) low energy consumption  4)Wearable and Durable

5)Fast and On time delivery  6)Best customer service!

Our Screw and Barrel processing production:

 CustomerOrder--ProductDesign(CustomerDrawing)—ProductionFlowArrangement—Material Procurement—Hardening&Tempering—Drilling—RoughTurning—RoughThread Rolling(AlloySprayWelding)—Alignment—FineThreadRolling—Mixing—Alignment—High FrequencyTreatment—Alignment—Polishing—Grinding—120HoursNitridingTreatment—Acid Piclking—Polishing—Chrome Plating—O.D.Grinding—Packaging&Shipping!

Our products package

Oiled,film wrapped in wooden case without fumigaiton

Our products quality certificate

Our other Products:



If you are still looking for supplier of screw barrel,why not give each other an opportunity?

ALice will be with you always,choosing us is your best choice,thanks!
