HDPE LDPE LLDPE screw barrel for 50/28 film blowing machine from China manufacturer

HDPE LDPE LLDPE screw barrel for 50/28 film blowing machine

Price:	1200.0~1600.0 USD
Payment Terms:	T/T,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: XR-SJ50/28

Production Capacity: 45kg/hr

Delivery Date: 25 working days upon receip...

Screw barrel material: High quality alloy steel 38...

Screw barrel certificate: ISO9001:2008

Screw barrel nitrided hours: 120 hours

Screw barrel hardness of nitrided layer: HV900-1100

Bimetalic screw processing way: PTA

Means of Transport: Ocean,Air

Packing: Film wrapped in wooden case...

Brand Name: SHEEN SCREW

Screw barrel HS code: 8477900000

Screw barrel application: HDPE LDPE LLDPE film blowin...

Screw barrel thickness of nitrided layer: 0.5-0.8mm

Bimetalic material: tungsten carbige 40%

Bimetallic layer of screw: 2.5mm

HDPE LDPE LLDPE screw barrel for 50/28 film blowing machine
Screw diameter:50mm L/D=28:1
We can do 30:1 32:1 screw barrel if you need.

About SHEEN SCREW

Zhoushan Sheen Machiney Company is leading supplier of SCREW and BARREL in china,including designing,manufacturing and sales for these products,we can make any specification of extruder screw barrel and injection molding screw barrel for Haitian,Demag,Engle,Nigrobossi,KMD,NPM,BOY,HUSKY, Nippon Steel, Toshiba, Nissei, Mitsubishi and etc. We also can supply all types of screw and barrel according to your different requirements.

What is our Screw and Barrel advantage:

First:Cretive in designs,our desinging team is very strong,since we have unique culture to motivate them,in order to meet requirement,we work closely to our customer and market!

Second:We have 15 years' experience of manufacturing varied screws, barrels and spares.We are keeping improving our production stytem day by day on the delievey,quality control,all the efforts have improved the customers satisfaction!

Third:We are located in China's screw Town-Jintang,Town in zhoushan city,near to Ningbo Port and Shanghai Port!

Finally,We assure the customer benefits,we supply best quality and competitive price,also best customer service!

HDPE LDPE LLDPE screw barrel for 50/28 film blowing machine Specification:

Screw diameter:Φ15mm-Φ360mm L/D=15-56

Length of screw and cylinder:8000mm

According to different material and plastic products to design different screw structure ,compress rate and L/D!
According to different material and plastic products to design different Barrel with exhaust system and IKV force load system!

As per customers' demand,we can supply below:
PVC/PE Film Blowing Screw; Blow Molding Screw; PS/PE/PP/ABS Sheet Extrusion Screw; PE Aluminum Plate;PPR Pipe Screw;EVA Extrusion Screw;HDPE High efficiency Screw;PET Straps Screw;XPS/EPE Foamed Screw;Granulation Screw,Vented single screw etc!

Detailed Technical Information:

Base Material	1)38CrMoAlA(JIS SACM645) 2)Cr12MOV(JIS SKD-11) 3)4Cr5MoSiV1(JIS SKD-61) 4)42CrMo(AISI 4140)
Bimetallic Alloy Materials	1)Fe-based alloy 2)Ni-based alloy/Deloro alloy 3)Co-based alloy 4)NiCo-based alloy 5)Tungsten carbide/Wolfram carbide
Double-alloy level	Level A - containing Tungsten of 40% Level B - containing tungsten of 25% Level C - containing tungsten of 9.5%
Surface Treatment	Heat Treatment High Frequency Treatment Nitriding treatment(120 Hours) Depth of Nitrided Layer: 0.5-0.8 mm Hardness of Nitrided Layer: 900-1020Hv (HRC56°-65°) Hard Chrome Plating treatment: Thickness of Hard Chrome Plating Layer: 0.05-0.10mm Hardness of Hard Chrome Plating Layer: ≥950HV Nickel alloy plating.treatment: Bimetallic Barrel/Cylinder: Centrifugal Casting (Inlay Alloy) Bimetallic Screw: Plasma Alloy Coating Spraying Depth of Bimetallic Layer: >2mm Hardness of Bimetallic Layer: HRC55°-72°
Basic information	Roughness of the surface:Ra0.4um Linearity of the screw: ≤0.015mm Linear axis limit: ≤0.02mm Hardness after Hardening & Tempering: HB240-280 Fragility of Nitration:≤Two class
Material Application	1)General Plastics 2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc 3)PA + GF(Glass Fiber) 4)Flame-resistant Reinforced Plastics 5)Modified Engineering Plastics 6)All kinds of Mixed Recycled Material(in Scrap or Granule),etc
General Terms	Means of transport: Ocean,Air,Express Production time: About 25 days after we receive the deposit and lead time will different according to the order quantity!
Our products advantages	1)High productivity 2)Wonderful plasticizing 3) low energy consumption 4)Wearable and Durable 5)Fast and On time delivery 6)Best customer service!

Our Screw and Barrel processing production:

CustomerOrder--ProductDesign(CustomerDrawing)—ProductionFlowArrangement—Material Procurement—Hardening&Tempering—Drilling—RoughTurning—RoughThread Rolling(AlloySprayWelding)—Alignment—FineThreadRolling—Mixing—Alignment—High FrequencyTreatment—Alignment—Polishing—Grinding—120HoursNitridingTreatment—Acid Piclking—Polishing—Chrome Plating—O.D.Grinding—Packaging&Shipping!

Our products package

We use standard export wooden case,film wrapped with oil

Our products quality certificate:

Our exhibition pictures:

If you are still loooking for suppliers of screw and barrel,why not give each other an opportunity to cooperate? Alice is be with you always,choosing us is your best choice! Thanks!

Download Attachment
